Asus ITX-220 Motherboard Intel Celeron 220 Intel 945GC Mini ITX SATA Gigabit LAN (Intel GMA 950)


£53.08 with Free Delivery
Debit Card Discounted Price: £52.81



Compare Competitor Prices

Similar Products


Image of Intel DN2800MT Desktop Motherboard Atom (D2800) 1.86GHz Socket BGA559 Intel NM10 Express Mini-ITX Gigabit LAN (Boxed)
Image of Intel Executive Series DQ77KB Desktop Motherboard Core i7/i5 Socket LGA 1155 Intel Q77 Express Thin Mini-ITX Gigabit LAN (Boxed)
Image of [Refurbished] Gigabyte C847N Motherboard Intel Dual-Core Celeron 847 Intel NM70 MITX Gigabit LAN (rev. 1.0) (Missing back plate)

£70.92 » £63.83
In Stock
Image of Intel Classic Series DH61DL Desktop Motherboard Intel 2nd Generation Core i7/i5/i3 Socket LGA1155 Intel H61 Express Mini-ITX Gigabit LAN with B3 Revision (Sinlge)
Image of Asus P8H61-I R2.0 Motherboard Core i7/i5/i3/Pentium/Celeron 1155 H61(B3) Mini ITX Gigabit LAN (Intergrated Graphics)

Important Information

  • Skinflint user promotional discount applied.
  • Images are for illustration purposes only. Actual product may differ from images shown.
  • Monitors are not included with PC systems unless stated.

Product Part Numbers

  • Quick Find Code: K112672
  • Manufacturers SKU: ITX-220
  • Product UPC/EAN:

Recommend this Product

Product Description


The Intel Graphics engine has new capabilities that provide a significant increase in graphics performance. DirectX 9 hardware acceleration, 400MHz core clock, and up to 224MB of video memory all together provide a full-value, high performance graphic solution to you. Through a dual-independent display technology, different content can be displayed on each monitor or stretched across both displays for more workspace. Enjoy high-end sound system on your PC! The onboard HD audio (High Definition Audio, previously codenamed Azalia) CODEC enables high-quality 192KHz/24-bit audio output, jack-sensing feature, retasking functions and multi-streaming technology that simultaneously sends different audio streams to different destinations. You can now talk to your partners on the headphone while playing a multi-channel network games. All of these are done on one computer.

Main Features:

  • Intel Celeron 220 on board
  • Intel 945GC/ ICH7 chipset
  • 2 x DDR2 DIMM sockets support up to 4GB of system memory
  • High Speed Gigabit Lan connectivity
  • Mini-ITX Form Factor

» Return to the top

Specifications


CPU Installed Processors (Max) 1 (1)
Processor Intel Celeron (220)
Supported Processor Manufacturer Intel
Supported Processors Intel Celeron 220
Socket Socket 479
MOTHERBOARD Chipset Intel 945GC ICH7
SATA Supported Yes SATA 3Gb/s
REAR PANEL I/O PORTS VGA Port 1 x D-Sub
Audio Line In Ports 1 x 6-Channel Audio I/O
Keyboard Port 1 x PS/2
Mouse Port 1 x PS/2
RJ-45 Ports 1 x RJ-45
USB Ports 4 x USB 2.0
Serial Ports 1 x COM
INTERNAL I/O CONNECTORS USB Connectors 1 x USB
Cooling Fan Support 1 x CPU / 1 x Chassis
Front Panel Connectors 1 x Front panel • 1 x Front audio
Chassis Intrusion Connector 1 x Chassis Intrusion Connector
EXPANSION PCI Slots 1 slot(s) - PCI
MEMORY Maximum Memory 4GB 533MHz DDR SDRAM ECC
Memory Slot 2 x DIMM Slots
GRAPHICS DEVICE Graphics Adaptor Yes Intel Graphics Media Accelerator 950
SOUND Integrated Sound VIA VT1705 6 -Channel High-Definition Audio CODEC
NETWORK Integrated Network Realtek PCI LAN Chipset
Network Speeds Supported 10/100/1000Mbps
SYSTEM BIOS 8 Mb Flash ROM, AMI BIOS, PnP, DMI v2.0, Wfm2.0, SM BIOS 2.5, ACPI v2.0a
Special Features ASUS MyLogo 2, ASUS EZ Flash 2, ASUS CrashFree BIOS 3
Software Included Drivers, ASUS PC Probe II, Anti-virus software (OEM version), ASUS Update
ELECTRICAL Power Connector 1 x 24-pin EPS 12V Power connector, 1 x 4-pin ATX 12V Power connector
PHYSICAL In The Box ITX-220 Motherboard, User's manual, 1 x I/O Shield, 1 x SATA cable
Dimensions 17.1cm (W) x 17.1cm (L)
