TP-LINK TL-SG1008D 8-Port Unmanaged Gigabit Desktop Switch


-28%
£31.43 » £22.67 with Free Delivery
Debit Card Discounted Price: £22.55


6 in Stock

Eligible Special Offers

Product Part Numbers

  • Quick Find Code: K168794
  • Manufacturers SKU: TL-SG1008D
  • Product UPC/EAN: 6935364020262

Product Description


You now have the choice to go green when upgrading to a gigabit network! This new generation TL-SG1008D 8-Port Gigabit Desktop Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network. Power down Idle Ports - When a computer or network equipment is off, the corresponding port of a traditional switch will continue to consume considerable amounts of power. The TL-SG1008D can automatically detect the link status of each port and reduce the power consumption of ports that are idle, resulting in up to an 80% reduction in power use. Power Budget According to Cable Length - Ideally, shorter cables would use less power because of less power degradation over their length, this is not the case with m.

Main Features:

  • Innovative energy-efficient technology saves power up to 80%
  • Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
  • Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
  • 16Gbps Switching Capacity
  • 9K Jumbo frame improves performance of large data transfers
  • Auto-MDI/MDIX eliminates the need for crossover cables
  • Supports MAC address auto-learning and auto-aging
  • Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps and 1000Mbps hardware
  • Fanless design ensures quiet operation
  • Desktop or wall-mounting design
  • Plug and Play design simplifies installation
» Return to the top

Specifications


PERFORMANCE Network Latency 10Base-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100Ù STP (maximum 100m) • 100Base-Tx: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100Ù STP (maximum 100m) • 1000Base-T: UTP category 5, 5e cable (maximum 100m)
Packet Forwarding Rate 10 Mbps: 14,880 pps • 100 Mbps: 148,800 pps • 1000 Mbps: 1,488,000pps
Topology Star
Backplane 16Gbps
MAC Addresses 8,000
INTERFACES/PORTS Network Speeds Supported 10/100/1000MBps
Fixed Ports 8 port(s) x RJ-45 , 10/100/1000Mbps , (Auto-MDI/MDIX)
COMPLIANCE Standards Compliance IEEE802.3, 802.3u, 802.3ab, 802.3x
Safety FCC, CE, RoHS
SYSTEM Management Capabilities Green Technology, saving power up to 80% • 802.3X Flow Control, Back Pressure • Auto-Uplink Every Port
Certifications Plug and play, no configuration required
Protocols Supported CSMA/CD, TCP/IP
SYSTEM REQUIREMENTS Operating Systems Supported Microsoft Windows • Linux • Mac OS X
ELECTRICAL Voltage/Power/Frequency 100 to 240VAC / 50 to 60Hz
Power Adaptor Type External
ENVIRONMENTAL Environmental Operating Temperature 0 to 40°C - Humidity 10 to 90%
PHYSICAL Case Colour Black
LED Status Indicators Power • Link/Activity
In The Box 8-Port Gigabit Desktop Switch • Power Adaptor • User Guide
Dimensions 16.5cm (W) x 10.8cm (D) x 2.8cm (H)
