Adaptec 6405 RAID Card 4-Port PCI Express 512MB for SATA/SAS Devices (Single - without Cables)


-30%
£354.99 » £249.55 with Free Delivery
Debit Card Discounted Price: £249.05


5 in Stock

Compare Competitor Prices

Product Part Numbers

  • Quick Find Code: K186746
  • Manufacturers SKU: 2270000-R
  • Product UPC/EAN: 0760884156421

Product Description


The Series 6 family of high-performance Adaptec Unified Serial (SATA/SAS) RAID controllers offers maximum performance, scalability and flexibility. With the enhanced bandwidth of its 6 Gb/s SAS2.0 interfaces and the PCIe Gen2 host connection it offers up to 60% higher sustained sequential throughput than previous generation controllers. Based on PMC-Sierra's market-leading, multi-core SRC 8x6G RAID-on-Chip (RoC) the Adaptec RAID 6405 can deliver up to 2 GB/s sustained data transfer rate to the host. Peak performance is up to 4.8GB/s through the SAS 2.0 interfaces and 4.0GB/s through the PCIe Gen2 host interface. Using SAS expanders, it can connect up to 256 SATA/SAS. The Adaptec RAID 6405 supports a broad range of operating systems, compatibility with more than 300 third-party devices, and full integration with Adaptec Storage Manager for centralized management of all Adaptec RAID controllers on the network.

Main Features:

  • 6 Gb/s throughput at each port
  • 512MB of DDR2 667MHz cache memory
  • Bus System Interface Type: 8-lane PCI-Express Gen2
  • PMC-Sierra PM8013 Dual Core RAID on Chip (ROC)
  • SAS 2.0 interfaces and PCIe Gen 2 Host Connection
  • 4 internal ports, low-profile MD2 form factor
  • Supports up to 256 SATA or SAS devices
  • Enclosure management support via LED header and SES2/ SGPIO
  • Intelligent Power Management - Reduces power and cooling costs by as much as 70%
  • Hybrid RAID 1 & 10: SSD + HDD for Maximum Performance and Reliability
» Return to the top

Specifications


ATTRIBUTES Card Type RAID Controller
Target System Environment High-end servers
Bus Type 8-lane PCl-Experss
Number of Supported Devices Supports up to 256 SATA or SAS devices
Drive Compatibility RAID 0, 1, 1E, 5, 5EE, 6, 10, 50, 60, JBOD
Protocol SNMP, SMTP
PERFORMANCE Data Transfer Rate Up to 6Gb/s
MEMORY Memory (Maximum) 512MB 667MHz DDR2
INTERFACES/PORTS Internal Connectors 1 x internal (SFF-8087)
SYSTEM Software Included Adaptec Storage Manager: Java-based GUI Management Utility; Remote configuration, monitoring and notification; ASM OS Support: Windows, Linux, SCO, Solaris; FreeBSD; Microsoft VDS Support; Remote firmware updates • ARCCONF: Command Line Interface • Adaptec BIOS Utility (ACU): BIOS-level configuration utility; Flashable BIOS support
SYSTEM REQUIREMENTS Operating Systems Supported Microsoft Windows • Red Hat Linux • SUSE Linux • Fedora • Debian Linux • Ubuntu Linux • Sun Solaris • FreeBSD • VMware ESX
COMPLIANCE Compliant Standards RoHS, REACH, WEEE
Certifications CE, FCC, UL, C-tick, VCCI, KCC
ENVIRONMENTAL Environmental Operating Temperature 0 to 55°C
PHYSICAL In The Box Adaptec RAID 6405 Controller; Additional low profile vented bracket; Quick Installation Guide (English/French/German/Italian/Spanish); Software and documentation CDs
Dimensions 6.4cm (W) x 16.7cm (H)
