Asus E35M1-M Motherboard Fusion E-350 Socket FT1 FCH A50 Hudson M1 uATX SATA Gigabit LAN (ATI Radeon HD 6310)


£128.00 with Free Delivery
Debit Card Discounted Price: £127.75


Similar Products


Product Part Numbers

  • Quick Find Code: K188312
  • Manufacturers SKU: E35M1-M
  • Product UPC/EAN: 4719543178522

Product Description


The ASUS EPU (Energy Processing Unit) provides total system power management by detecting current PC loadings and intelligently moderating power in real-time. It automatically provides the most appropriate power usage to save power and money! Enjoy superb performance by auto-tuning your processor to an extreme yet stable state. Simply activate a dedicated switch on the motherboard to unleash extra processing capabilities. ASUS brand new EFI BIOS offers a user-friendly interface that goes beyond traditional keyboard only BIOS, to enable more flexible and convenient mouse controls. Users can easily navigate the new EFI BIOS with the same smoothness as their operating system. The exclusive EZ Mode displays frequently-accessed setup info, while the Advanced Mode is for experienced performance enthusiasts that demand far more intricate system settings.  .

Main Features:

  • Protect30 - EPU, Anti-Surge, Low EMI
  • DX 11 Support - More detailed and realistic terrain
  • USB 30 - 10x faster than USB20
  • Native SATA 6Gb/s - Native Ports, Native Speed and Accessibility
  • EFI BIOS(EZ Mode) - Flexible & Easy BIOS Interface
  • AI Suite II - One-Stop Access to Innovative ASUS Features
» Return to the top

Specifications


CPU Supported Processors AMD Fusion APU E-350 Dual-Core onboard Processors • AMD Cool 'n' Quiet Technology • Up to 2 Bobcat cores, FT1 BGA
Socket FT1 (BGA-413)
MOTHERBOARD Chipset AMD
SATA Supported Yes
REAR PANEL I/O PORTS Keyboard/Mouse Combo Port 1 x PS/2
USB Ports 6 x USB
RJ-45 Ports 1 x RJ-45
HDMI Port 1 x HDMI
VGA Port 1 x D-Sub
Digital Port 1 x DVI
eSATA Ports 1 x eSATA
Audio Line Out Ports 3 x Audio Jack
S/PDIF Port 1 x S/PDIF out (Optical)
Firewire Ports 1 x IEEE 1394a
INTERNAL I/O CONNECTORS Front Panel Connectors 1 x Front Audio Header
Cooling Fan Support 1 x CPU / 1 x Chassis
SATA Connectors 5 x SATA 6Gb/s
S/PDIF Connectors 1 x S/PDIF out
USB Connectors 4 x USB 2.0 Connectors (Supports 8 ports)
Firewire Connectors 1 x IEEE 1394a Connector
Parallel Connectors 1
Serial Connectors 1 x COM
Power Connector Port 1 x 24-pin EATX • 1 x 4-pin ATX 12V
Other Connectors 1 x System panel(s) • 1 x Turbo Key II switch(es)
EXPANSION PCI Slots 2 slot(s) - PCI
PCI Express Slots 2 slot(s) - 1 x PCIe 2.0 x16, 1 x PCIe 2.0 x1 ,
MEMORY Maximum Memory 8GB 1066MHz DDR3
Memory Slot 2 x DIMM Slots
GRAPHICS DEVICE Graphics Adaptor Yes ATI Radeon HD 6310
SOUND Integrated Sound Realtek ALC 887-VD2 8-Channel High Definition Audio CODEC 2 • Supports : Multi-streaming, Front Panel Jack-retasking, Anti-pop Function • Audio Feature : • Optical S/PDIF out port(s) at back panel
NETWORK Integrated Network Realtek 8111E
SYSTEM BIOS 32 Mb Flash ROM , EFI BIOS, PnP, DMI 2.0, WfM 2.0, ACPI 2.0a, SM BIOS 2.5
Special Features ASUS EPU : • EPU • Turbo Key • Turbo Key II • TurboV • ASUS Exclusive Features : • AI Suite II • Anti-Surge • Low EMI Solution- • ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface • ASUS Quiet Thermal Solution :- • ASUS Fan Xpert • ASUS EZ DIY : • ASUS CrashFree BIOS 3 • ASUS EZ Flash 2 • ASUS MyLogo 2
Software Included Drivers • ASUS PC Probe II • Anti-virus software (OEM version) • ASUS Update
Overclocking Features ASUS C.P.R.(CPU Parameter Recall)
COMPLIANCE Certifications RoHS
PHYSICAL In The Box Motherboard • User's manual • I/O Shield • 2 x SATA 6Gb/s cable(s)
Dimensions 18.3cm (W) x 24.4cm (L)
