Gigabyte D525TUD Motherboard Dual Core Atom D525 Intel NM10 Mini-ITX RAID Gigabit Ethernet (rev.1.x)


£79.43 with Free Delivery
Debit Card Discounted Price: £79.03



Compare Competitor Prices

Similar Products


Image of Intel Executive Series DQ77KB Desktop Motherboard Core i7/i5 Socket LGA 1155 Intel Q77 Express Thin Mini-ITX Gigabit LAN (Boxed)
Image of Intel DN2800MT Desktop Motherboard Atom (D2800) 1.86GHz Socket BGA559 Intel NM10 Express Mini-ITX Gigabit LAN (Boxed)
Image of [Refurbished] Gigabyte C847N Motherboard Intel Dual-Core Celeron 847 Intel NM70 MITX Gigabit LAN (rev. 1.0) (Missing back plate)

£104.51
In Stock
Image of Intel MB BOXD2550MUD2/mini-ITX NM10 DDR3-1066

£89.08 » £62.05
In Stock
Image of ASRock A75M-ITX Motherboard Socket FM1 AMD A75 FCH Hudson-D3 Mini ITX RAID Gigabit LAN AMD (Radeon HD 65XX/64XX)

Important Information

  • Images are for illustration purposes only. Actual product may differ from images shown.
  • Monitors are not included with PC systems unless stated.

Product Part Numbers

  • Quick Find Code: K192491
  • Manufacturers SKU: GA-D525T-UD
  • Product UPC/EAN: 4719331828226

Recommend this Product

Product Description


The ErP (as known as Energy-Related Products Directive) is part of new European Union's environment regulations. ErP established is based on the concern of environmental issues regards electronic devices been gained popularity and how to improve energy efficiency for better and greener life. GIGABYTE presents standard motherboards to help you effectively improving system performance and saving more energy.

Main Features:

  • Ultra Durable 3 Technology with copper cooled quality for lower working temperature
  • 3X USB power delivery for greater compatibility and extra power for USB devices
  • Support 45nm Intel Atom D525dual core processor
  • Maximum Supported Memory: 4GB (Due to Windows 32-bit operating system limitation, when the 4GB of physical memory is installed, the actual memory size displayed will be less than 4GB)
  • Integrated Intel graphic with DirectX 9 support
  • Integrated High Definition audio
  • Features high speed Gigabit Ethernet connection
  • Patented DualBIOS with dual hardware BIOS protection
  • Total 4 SATA ports and IDE interface support for multiplex connectivity
  • Features SATA 3Gb/s with RAID function
  • Compatible with Window 7 to deliver the best operation experience

» Return to the top

Specifications


CPU Installed Processors (Max) 1 (1)
Processor Intel Dual Core Atom (D525) 1.8GHz 1024KB (L2 Cache)
Socket Socket BGA 559
MOTHERBOARD Chipset Intel NM10
Input/Output Controller ITE IT8720
RAID Supported Yes RAID 0, RAID 1, JBOD
SATA Supported Yes SATA 3Gb/s
IDE/EIDE Supported Yes ATA 133/100/66/33
REAR PANEL I/O PORTS Keyboard Port 1 x PS/2
Mouse Port 1 x PS/2
RJ-45 Ports 1 x RJ-45 Port
USB Ports 4 x USB 2.0
Parallel Ports 1 x Parallel
Serial Ports 1 x Serial
INTERNAL I/O CONNECTORS SATA Connectors 4 x SATA 3Gb/s
IDE Connectors 1 x IDE connector
USB Connectors 2 x USB 2.0
Cooling Fan Support 1 x CPU Fan 1 x System Fan
Front Panel Connectors 1 x front panel header • 1 x front panel audio header
Chassis Intrusion Connector 1 x Chassis Intrusion Header
Power Connector Port 1 x Power LED Header
EXPANSION PCI Slots 1 slot(s) - PCI
MEMORY Maximum Memory 4GB 800MHz DDR3
Memory Slot 2 x DIMM Slots
SOUND Integrated Sound Realtek ALC888B codec • High Definition Audio • 2/4/5.1/7.1-channel (To enable 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver)
NETWORK Integrated Network Realtek RTL8111E
Network Speeds Supported 10/100/1000Mbps
SYSTEM REQUIREMENTS Operating Systems Supported Support for Microsoft Windows 7/Vista/XP
SYSTEM BIOS 2x4 Mbit flash • Use of licensed AWARD BIOS • Support for DualBIOS • PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Special Features Support for @BIOS • Support for Q-Flash • Support for Xpress BIOS Rescue • Support for Download Center • Support for Xpress Install • Support for Xpress Recovery2 • Support for EasyTune • Support for SMART Recovery • Support for Auto Green • Support for ON/OFF Charge • Support for Q-Share
ELECTRICAL Power Connector 1 x 20-pin ATX main power connector • 1 x 4-pin ATX 12V power connector
PHYSICAL Dimensions 17.0cm (W) x 17.0cm (L)
