Asus M5A88-M EVO Motherboard AMD PhenomII/AthlonII/Sempron 100 Socket AM3 uATX RAID Gigabit LAN (ATI Radeon HD 4250)


£124.75 with Free Delivery
Debit Card Discounted Price: £124.13


Compare Competitor Prices

Similar Products


Product Part Numbers

  • Quick Find Code: K193685
  • Manufacturers SKU: M5A88-M EVO
  • Product UPC/EAN: 4719543180860

Product Description


High-Definition Multimedia Interface (HDMI) is a set of digital video standards that delivers multi-channel audio and uncompressed digital video for full HD 1080p visuals through through a single cable. Supporting HDCP copy protection such as HD DVD and Blu-ray Discs, HDMI provides you with the highest-quality home theater experience. The motherboard supports DDR3 memory that features data transfer rates of 2000(O.C.)/1333/1066 MHz to meet the higher bandwidth requirements of the latest 3D graphics, multimedia, and Internet applications. The dual-channel DDR3 architecture enlarges the bandwidth of your system memory to boost system performance.

Main Features:

  • AM3+ CPU Support Ready
  • Dual Intelligent Processors - TPU & EPU
  • Core Unlocker - Unlock the Potential, Turbocharge your Performance!
  • GPU Boost Instant - iGPU Level Up!
  • Turbo Unlocker - On demand real-time system
  • True USB 3.0 & SATA 6Gb/s Support - Fully Unleash Performance
» Return to the top

Specifications


CPU Installed Processors (Max) 0 (1)
Supported Processor Manufacturer AMD
Supported Processors AMD AM3+ FX/Phenom II/Athlon II/Sempron 100 Series Processors Supports AM3+ 32 nm CPUSupports CPU up to 140 WAMD Cool 'n' Quiet Technology
64-bit Support Yes
Socket Socket AM3
Front Side Bus 5.2 GT/s HyperTransport
MOTHERBOARD Chipset AMD 880G SB850
RAID Supported Yes RAID 0, RAID 1, RAID 5, RAID 10, JBOD
SATA Supported Yes
REAR PANEL I/O PORTS VGA Port 1 x D-Sub
Digital Port 1 x DVI
HDMI Port 1 x HDMI
S/PDIF Port 1 x Optical S/PDIF-out
Keyboard/Mouse Combo Port 1 x PS/2
RJ-45 Ports 1 x RJ-45
USB Ports 4 x USB 2.0 • 2 x USB 3.0
eSATA Ports 1 x eSATA
INTERNAL I/O CONNECTORS SATA Connectors 5 x SATA 6Gb/s
S/PDIF Connectors 1 x S/PDIF out Header
USB Connectors 4 x USB 2.0 Connectors (Supports 8 ports)
Serial Connectors 1 x COM
Parallel Connectors 1
Cooling Fan Support 1 x CPU / 1 x Chassis / 1 x Power Fan connectors
Front Panel Connectors 1 x Front audio connector
Power Connector Port 1 x 24-pin EATX • 1 x 4-pin ATX 12V
Other Connectors 1 x System panel(s) • 1 x MemOK! button(s) • 1 x Core Unlocker switch(es) • 1 x TPU switch(es)
EXPANSION PCI Slots 1 slot(s) - PCI
PCI Express Slots 3 slot(s) - 1 x PCIe 2.0 x16 , 2 x PCI Express x1
MEMORY Maximum Memory 16GB 1066/1333MHz DDR3 (Unbuffered Non-ECC)
Memory Slot 4 x DIMM Slots
GRAPHICS DEVICE Graphics Adaptor Yes ATI Radeon HD4250
SOUND Integrated Sound Realtek ALC 892 8-Channel High Definition Audio CODEC • Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking • Audio Feature : • Absolute Pitch 192kHz/ 24-bit True BD Lossless Sound • Optical S/PDIF out port(s) at back panel
NETWORK Integrated Network Realtek 8111E
SYSTEM BIOS 16 Mb Flash ROM, AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a, ASUS EZ Flash 2, ASUS CrashFree BIOS 3
Special Features ASUS Dual Intelligent Processors - TPU & EPU : • ASUS TPU : • Turbo Unlocker • Auto Tuning • TurboV • CPU Level Up • GPU Boost • TPU switch • ASUS Hybrid Switch : • Core Unlocker • ASUS Power Design : • 4 +1 Phase Power Design • ASUS Exclusive Features : • MemOK! • Anti-Surge • ASUS Quiet Thermal Solution : • Stylish Fanless Design Heat-sink solution • ASUS Fan Xpert • ASUS EZ DIY : • ASUS O.C. Profile • ASUS CrashFree BIOS 3 • ASUS EZ Flash 2 • ASUS MyLogo 2
Overclocking Features ASUS C.P.R.(CPU Parameter Recall)
Software Included Drivers • ASUS PC Probe II • ASUS Update • AMD OverDrive Utility (AOD) • Anti-virus software (OEM version)
PHYSICAL In The Box Motherboard • User's manual • I/O Shield • 2 x SATA 6Gb/s cable(s)
Dimensions 24.4cm (W) x 24.4cm (L)
