TP-LINK TL-SG3210 8-Port Gigabit L2 Lite Managed Switch with 2 SFP Slots


-18%
£94.75 » £78.07 with Free Delivery
Debit Card Discounted Price: £77.92


14 in Stock

Product Part Numbers

  • Quick Find Code: K203768
  • Manufacturers SKU: TL-SG3210
  • Product UPC/EAN: 6935364020972

Product Description


Moreover, the switch supports 802.1X authentication, which is used in conjunction with a RADIUS server to require some authentication information before access to the network is allowed. Guest VLAN function supports to enable the non-802.1X clients to access the specific network resource. To integrate voice, data and video service on one network, the switch applies rich QoS policies. Administrator can designate the priority of the traffic based on a variety of means including IP or MAC address, TCP or UDP port number, etc, to ensure that voice and video are always clear, smooth and jitter free. In conjunction with the Voice VLAN the switch supporting, the voice applications will operate with much smoother performance. For more application of layer 2 switches, TL-SG3210 supports a complete lineup of layer 2 features, including 802.1Q tag VLAN, Port Isolation, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol and 802.3x Flow Control function. Any more, the switch provides advanced features for network maintenance. Such as Loop Back Detection, Cable Diagnostics and IGMP Snooping. IGMP snooping ensures the switch intelligently forward the multicast stream only to the appropriate subscribers while IGMP throttling & filtering restrict each subscriber on a port level to prevent unauthorized multicast access.

Main Features:

  • Layer 2 Features
  • Link Aggregation Control Protocol (LACP)
  • Port Isolation
  • Quality of Service
  • 4 priority queues
  • Support IEEE 802.1P
  • Rate limit feature
  • IP-MAC-Port-VID Binding
  • Access Control List (L2~L4 ACL)
  • 802.1x and RADIUS Authentication
  • Port Security
  • SSL and SSH encryptions
  • Web-based GUI
  • Command Line Interface
» Return to the top

Specifications


MEMORY Buffer Memory 0.5MB
ROUTING Layer 2 Services IGMP Snooping V1/V2/V3 • 802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group) • Spanning Tree STP/RSTP/MSTP • Port isolation • BPDU filtering/guard • TC/Root protect • Loop back detection • 802.3x Flow Control
PERFORMANCE Backplane 20Gbps
MAC Addresses 8,000
Network Latency 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • 100BASE-TX/1000Base-T: UTP category 5, 5e, 6 or above cable (maximum 100m) • 1000BASE-X: MMF, SMF
Packet Forwarding Rate 14.9mpps
INTERFACES/PORTS Network Speeds Supported 10/100/1000MBps
Fixed Ports 8 port(s) x RJ-45 , 10/100/1000Mbps , (Auto-MDI/MDIX)
Network Slots 2 slot(s) x SFP ,
Console Ports 1 x RJ-45
COMPLIANCE Safety CE, FCC
SYSTEM Management Capabilities Web-based GUI and CLI management • SNMP v1/v2c/v3,compatible with public MIBs and TP-LINK private MIBs • RMON (1, 2, 3, 9 groups) • DHCP/BOOTP Client,DHCP Snooping,DHCP Option82 • CPU Monitoring • Port Mirroring • Time Setting: SNTP • Integrated NDP/NTDP feature • Firmware Upgrade: TFTP & Web • System Diagnose: VCT • SYSLOG & Public MIBS
Ethernet Switching Features Support 802.1p CoS/DSCP priority • Support 4 priority queues • Queue scheduling: SP, WRR, SP+WRR • Port/Flow- based Rate Limiting • Voice VLAN
Security IP-MAC-Port-VID Binding • IEEE 802.1X Port/MAC Based authentication, Radius,Guest VLAN • DoS Defence • Dynamic ARP inspection (DAI) • SSH v1/v2 • SSL v2/v3/TLSv1 • Port Security • Broadcast/Multicast/Unknown-unicast Storm Control
Protocols Supported Support IEEE802.1Q with 4K VLAN groups and 4K VIDs • Port/ MAC/Protocol-based VLAN • GARP/GVRP • Management VLAN configuration
ELECTRICAL Voltage/Power/Frequency 100 to 240VAC / 50 to 60Hz
ENVIRONMENTAL Environmental Operating Temperature 0 to 40°C - Humidity 10 to 90%
PHYSICAL In The Box Switch • Power Cord • Quick Installation Guide • Resource CD • Rackmount Kit • Rubber Feet
Dimensions 29.4cm (W) x 18.0cm (D) x 4.4cm (H)
