TP-LINK TL-SF1024D 24-Port 10/100Mbps Switch

~~£35.19~~ » £34.76 with Free Delivery

Debit Card Discounted Price: £34.59

2 in Stock —

Compare Competitor Prices

Amazon.co.uk — £31.93

Important Information

Images are for illustration purposes only. Actual product may differ from images shown.
Monitors are not included with PC systems unless stated.

Product Tools

Products Suggestions

Product Part Numbers

Quick Find Code: K203976
Manufacturers SKU: TL-SF1024D
Product UPC/EAN: 6935364020828

Product Description

The TL-SF1024D Fast Ethernet Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network. It also complies with the EU'S RoHS, prohibiting the use of certain hazardous materials. Besides, 70% of the packaging material can be recycled. The auto features of this fast ethernet switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.

Main Features:

Innovative energy-efficient technology saves power up to 75%
Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
4.8 Gbps Switching Capacity
Store and forward Switching scheme
Auto-MDI/MDIX eliminates the need for crossover cables
Supports MAC address auto-learning and auto-aging
Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps hardware
Plug and Play design simplifies installation
Fanless design to make sure it works quietly without disturbing your family

» Return to the top

Specifications

PERFORMANCE	Backplane	4.8Gbps
	MAC Addresses	8,000
	Network Latency	10Base-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100U STP (maximum 100m) • 100Base-Tx: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ù STP (maximum 100m)
	Packet Forwarding Rate	148,800pps
	Port Bandwidth	10/100Mbps
INTERFACES/PORTS	Full Duplex Capabilities	All ports via Auto-Negotiation
	Fixed Ports	24 port(s) x RJ-45 , 10/100Mbps , (Auto-MDI/MDIX)
COMPLIANCE	Standards Compliance	IEEE802.3, 802.3u, 802.3x
	Safety	FCC, CE
SYSTEM	Protocols Supported	CSMA/CD, TCP/IP
ELECTRICAL	Voltage/Power/Frequency	100 to 240VAC / 50 to 60Hz
	Power Adaptor Type	External
ENVIRONMENTAL	Environmental	Operating Temperature 0 to 40°C - Humidity 10 to 90%
PHYSICAL	LED Status Indicators	Power, Link/Act, 100Mbps
	Dimensions	29.4cm (W) x 18.0cm (D) x 4.4cm (H)
