TP-LINK TL-SF1024D 24-Port 10/100Mbps Switch


-11%
£37.32 » £33.16 with Free Delivery
Debit Card Discounted Price: £33.09


Last 2 — Get yours now!

Compare Competitor Prices

Product Part Numbers

  • Quick Find Code: K203976
  • Manufacturers SKU: TL-SF1024D
  • Product UPC/EAN: 6935364020828

Product Description


The TL-SF1024D Fast Ethernet Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network. It also complies with the EU'S RoHS, prohibiting the use of certain hazardous materials. Besides, 70% of the packaging material can be recycled. The auto features of this fast ethernet switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.

Main Features:

  • Innovative energy-efficient technology saves power up to 75%
  • Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
  • Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
  • 4.8 Gbps Switching Capacity
  • Store and forward Switching scheme
  • Auto-MDI/MDIX eliminates the need for crossover cables
  • Supports MAC address auto-learning and auto-aging
  • Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps hardware
  • Plug and Play design simplifies installation
  • Fanless design to make sure it works quietly without disturbing your family
» Return to the top

Specifications


PERFORMANCE Backplane 4.8Gbps
MAC Addresses 8,000
Network Latency 10Base-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100U STP (maximum 100m) • 100Base-Tx: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ù STP (maximum 100m)
Packet Forwarding Rate 148,800pps
Port Bandwidth 10/100Mbps
INTERFACES/PORTS Full Duplex Capabilities All ports via Auto-Negotiation
Fixed Ports 24 port(s) x RJ-45 , 10/100Mbps , (Auto-MDI/MDIX)
COMPLIANCE Standards Compliance IEEE802.3, 802.3u, 802.3x
Safety FCC, CE
SYSTEM Protocols Supported CSMA/CD, TCP/IP
ELECTRICAL Voltage/Power/Frequency 100 to 240VAC / 50 to 60Hz
Power Adaptor Type External
ENVIRONMENTAL Environmental Operating Temperature 0 to 40°C - Humidity 10 to 90%
PHYSICAL LED Status Indicators Power, Link/Act, 100Mbps
Dimensions 29.4cm (W) x 18.0cm (D) x 4.4cm (H)
