TP-LINK TL-ER5120 Gigabit Load Balance Broadband Router

£168.69 » £136.94 with Free Delivery
Debit Card Discounted Price: £136.67

Last 2 — Get yours now!

Compare Competitor Prices

Product Part Numbers

  • Quick Find Code: K206938
  • Manufacturers SKU: TL-ER5120
  • Product UPC/EAN: 6935364041113

Product Description

By setting PPPoE Server to allocate PPPoE account to the private network users, the router only allows the users with legal account and passed the authentication to access the Internet via. Cooperating with IP-based Bandwidth Control, it is capable to confine the bandwidth usage of certain PPPoE account. Moreover, the E-Bulletin function is able to release bulletin in the form of webpage to certain user groups periodically, which notifies the users about the expiration date of the PPPoE account. With the above features, the router will prioritize different users in surfer jurisdiction for a better reasonable management. The TL-ER5120 features three free changeable ports that can be set to either LAN or WAN, allowing the router to support up to four WAN ports to satisfy various Internet access requirements through one device. The Intelligent Load Balancing function can distribute data streams according to the bandwidth proportion of every WAN port to raise the utilization rate of multi-line broadband. With IP-based Bandwidth Control and Session Limit functions, network administrators can flexibly manage network bandwidth to optimize bandwidth usage.

Main Features:

  • 1 fixed gigabit WAN port, 1 fixed gigabit LAN/DMZ port and 3 free changeable gigabit WAN/LAN ports
  • Abundant security features including ARP Inspection, DoS Defence, URL/Keyword Domain Filter and Access Control
  • Deploys One-Click restriction of IM/P2P applications to manage staff online behavior
  • Supports PPPoE Server for the better management of internal network
  • Load Balancing, automatically selects the best line according to the load
  • Professional 4kV lightning protection keeps your investments as safe as possible
» Return to the top


PERFORMANCE Throughput 350 Mbps
MTBF 120,000Hrs
SECURITY Security ARP Inspection: Sending GARP Packets; ARP Scanning by WAN/LAN; IP-MAC Binding • Application Control: IM, P2P, Web IM, Web SNS, Web Media, Protocol, Proxy Blocking • Attack Defense: TCP/UDP/ICMP Flood Defense; Block TCP Scan (Stealth FIN/Xmas/Null); Block Ping from WAN • DMZ Port: 1 Hardware DMZ Port
Firewall Filtering MAC Filtering; URL/Keywords Filtering; Web Content Filtering (Java, ActiveX, Cookies)
Ethernet Standards IEEE 802.3, 802.3u, 802.3z, 802.3ab
INTERFACES/PORTS Console Port 1 x RJ-45
WAN Ports 1 port(s) x RJ-45 10/100/1000Mbps
LAN Ports 4 port(s) x RJ-45 10/100/1000Mbps
MEMORY Memory (Maximum) 128MB DDR2
Flash Memory 8MB
SYSTEM Management Maintenance: Web/CLI/Telnet Management Interface • Remote Management • Export & Import Configuration • NTP Synchronize • Syslog Support; Service: PPPoE Server • E-Bulletin • Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)
SYSTEM REQUIREMENTS System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux
ELECTRICAL Power Adaptor Type Internal
Voltage/Power/Frequency 100 to 240VAC / 50 to 60Hz
ENVIRONMENTAL Environmental Humidity 10 to 90% Operating Temperature 0 to 40°C
PHYSICAL Form Factor 1U Rackmount
LED Status Indicators PWR, SYS, Link/Act, Speed, WAN, DMZ
In The Box TL-ER5120 • Resource CD • Power Cord • Rack-mount Kit • Installation Guide
Dimensions 44.0cm (W) x 22.0cm (D) x 4.4cm (H)
