Asus M5A78L-M LX V2 Motherboard AMD Socket AM3+ 760G MATX VGA Gigabit LAN (ATI Radeon HD)


-14%
£45.99 » £39.49 with Free Delivery
Debit Card Discounted Price: £39.41


Similar Products


Product Part Numbers

  • Quick Find Code: K211228
  • Manufacturers SKU: M5A78L-M LX V2
  • Product UPC/EAN: 4719543180372

Product Description


Enjoy an instant performance boost by simply unlocking the extra cores, without performing complicated BIOS changes.  Anti-Surge Protection Design detects overvoltage conditions and prevents voltage surges from spreading in real time. It also actively cuts off the overvoltage supply to protect the system.  1. Real-time over voltage detection.  2. Active protection against potential damage to your motherboards and systems.

Main Features:

  • EPU-4 Engine
  • Core Unlocker
  • Turbo Key
  • ESD
  • ASUS Anti-Surge Protection
  • 8-channel High Definition Audio
  • C.P.R.(CPU Parameter Recall)
  • EZ-Flash 2
  • ErP ready
» Return to the top

Specifications


CPU Supported Processors Phenom II/Athlon II/Sempron 100 Series Processors
Installed Processors (Max) 0 (1)
Supported Processor Manufacturer AMD
REAR PANEL I/O PORTS Parallel Ports 1 x Parallel
USB Ports 4 x USB 2.0
Keyboard Port 1 x PS/2
Mouse Port 1 x PS/2
RJ-45 Ports 1 x RJ-45
VGA Port 1 x D-Sub
Audio Line In Ports 3 x 5.1 Audio jack
INTERNAL I/O CONNECTORS Front Panel Connectors 1 x Front Audio Header
Cooling Fan Support 1 x CPU
SATA Connectors 6 x SATA II 3Gb/s
S/PDIF Connectors 1
USB Connectors 3 x USB 2.0 Connectors
Power Connector Port 1 x 24-pin EATX • 1 x 4-pin ATX 12V
EXPANSION PCI Slots 1 slot(s) - PCI
PCI Express Slots 3 slot(s) - 1 x PCI Express 2.0 x16 slot (blue @ x16 mode) • 2 x PCI Express 2.0 x1 slots ,
MEMORY Maximum Memory 8GB DDR3 (Unbuffered Non-ECC)
GRAPHICS DEVICE Graphics Adaptor Yes ATI Radeon HD
NETWORK Integrated Network Realtek 8111E
SYSTEM BIOS 16 MB Flash ROM, AMI BIOS
Software Included Drivers • ASUS PC Probe II • ASUS Update • Anti-virus software (OEM version)
SLi/Crossfire Features Hybrid CrossFireX
PHYSICAL In The Box Asus M5A78L-M LX V2 Motherboard • User's manual • I/O Shield • 2 x SATA 3Gb/s cable(s)
