D-Link DGE-528T Copper Gigabit PCI Card for PC


-24%
£14.40 » £10.93 with Free Delivery
Debit Card Discounted Price: £10.91


100+ in Stock

Product Part Numbers

  • Quick Find Code: I5841559
  • Manufacturers SKU: DGE-528T
  • Product UPC/EAN: 0790069263552

Product Description


Wake-On-LAN (WOL) is an Advanced Configuration Power Interface (ACPI) function allowing a powered OFF computer to be powered ON from a remote station. This function allows the administrator to send wake-up signals to a computer. The WOL function provides a great utility for power management of the PC and allows users to initiate action at irregular times and from distant locations. The card's embedded flow control and independent FIFO provide a means to protect against possible data loss during transmission on the network. When connected to a Gigabit switch supporting flow control, the card receives signals from the switch regarding buffer overrun during peak usage periods. The card then delays transmission until the switch is ready again to accept new data. Using a single chip solution, this card is very small in size and consumes very little power of your computer system.

Main Features:

  • Copper Gigabit connection for PC
  • 10/100/1000Mbps auto-sensing speeds
  • 2000Mbps Gigabit full duplex support
  • 32-bit 33/66MHz clock speed PCI Bus Master operation
  • Built-in FIFO (8K/64K) buffer to reduce overhead of memory transfers
  • Supports auto MDI/MDIX
  • 802.3x Flow Control for fast, reliable data transmission
  • Supports ACPI 2.0 WOL power management
  • Supports 802.1Q VLAN Tagging
  • PCI 2.1, 2.2 plug-and-play
  • Runs Win98, 2000, ME, NT, XP, NetWare, Linux, MacOS
  • Very small size, very low power consumption
» Return to the top

Specifications


NETWORK Network Speeds Supported 10/100/1000Mbps
Protocol CSMA/CD
SYSTEM REQUIREMENTS Operating Systems Supported Microsoft Windows 98, Me, NT 4.0, 2000, XP • Novell NetWare Server 5.x, 6.x • Linux kernel 2.2.x, 2.4.x • Macintosh OS X
COMPLIANCE Compliant Standards IEEE 802.3 10BASE-T Ethernet • IEEE 802.3u 100BASE-TX Fast Ethernet • IEEE 802.3ab 1000BASE-T Gigabit Ethernet • ANSI/IEEE 802.3 NWay auto-negotiation • PCI local bus 2.1, 2.2 specifications • IEEE 802.3x Flow Control • IEEE 802.1Q VLAN tagging
ENVIRONMENTAL Environmental Operating Temperature 0 to 50°C - Humidity 10 to 90%
PHYSICAL Status Indicators 1000/100/10Mbps • Full duplex
