D-Link DGE-528T Copper Gigabit PCI Card for PC

~~£14.40~~ » £11.71 with Free Delivery

Debit Card Discounted Price: £11.65

100+ in Stock —

Compare Competitor Prices

Amazon.co.uk — £10.97

Important Information

Images are for illustration purposes only. Actual product may differ from images shown.
Monitors are not included with PC systems unless stated.

Product Tools

Products Suggestions

Product Part Numbers

Quick Find Code: I5841559
Manufacturers SKU: DGE-528T
Product UPC/EAN: 0790069263552

Product Description

Wake-On-LAN (WOL) is an Advanced Configuration Power Interface (ACPI) function allowing a powered OFF computer to be powered ON from a remote station. This function allows the administrator to send wake-up signals to a computer. The WOL function provides a great utility for power management of the PC and allows users to initiate action at irregular times and from distant locations. The card's embedded flow control and independent FIFO provide a means to protect against possible data loss during transmission on the network. When connected to a Gigabit switch supporting flow control, the card receives signals from the switch regarding buffer overrun during peak usage periods. The card then delays transmission until the switch is ready again to accept new data. Using a single chip solution, this card is very small in size and consumes very little power of your computer system.

Main Features:

Copper Gigabit connection for PC
10/100/1000Mbps auto-sensing speeds
2000Mbps Gigabit full duplex support
32-bit 33/66MHz clock speed PCI Bus Master operation
Built-in FIFO (8K/64K) buffer to reduce overhead of memory transfers
Supports auto MDI/MDIX
802.3x Flow Control for fast, reliable data transmission
Supports ACPI 2.0 WOL power management
Supports 802.1Q VLAN Tagging
PCI 2.1, 2.2 plug-and-play
Runs Win98, 2000, ME, NT, XP, NetWare, Linux, MacOS
Very small size, very low power consumption

» Return to the top

Specifications

NETWORK	Network Speeds Supported	10/100/1000Mbps
	Protocol	CSMA/CD
SYSTEM REQUIREMENTS	Operating Systems Supported	Microsoft Windows 98, Me, NT 4.0, 2000, XP • Novell NetWare Server 5.x, 6.x • Linux kernel 2.2.x, 2.4.x • Macintosh OS X
COMPLIANCE	Compliant Standards	IEEE 802.3 10BASE-T Ethernet • IEEE 802.3u 100BASE-TX Fast Ethernet • IEEE 802.3ab 1000BASE-T Gigabit Ethernet • ANSI/IEEE 802.3 NWay auto-negotiation • PCI local bus 2.1, 2.2 specifications • IEEE 802.3x Flow Control • IEEE 802.1Q VLAN tagging
ENVIRONMENTAL	Environmental	Operating Temperature 0 to 50°C - Humidity 10 to 90%
PHYSICAL	Status Indicators	1000/100/10Mbps • Full duplex

» Return to the top

Reviews

Write a review, and share your thought on this product.

Reviewed by: L. W. Slee

My computer only had USB ports, which were fine, until I upgraded to broadband. The instructions recommended connecting the modem via an ethernet cable. It was very easy to fit the adapter into my computer and it was recognised and worked as soon as the computer was switched on. Anyone should be able to easily carry out this upgrade.

Sunday 12 July, 2009

See all customer reviews...
