Full Specifications
References
Quick Find Code EXD/1457568
Manufacturer / Brand TP-LINK
SKU TD-W8961N
Router
Router Type ADSL2+
WAN
WAN Standards ADSL Standards: Full-rate ANSI T1.413 Issue 2; ITU-T G.992.1(G.DMT); ITU-T G.992.2 (G.Lite); ITU-T G.994.1 (G.hs); ITU-T G.995.1 • ADSL2 Standards: ITU-T G.992.3 (G.dmt.bis); ITU-T G.992.4 (G.lite.bis) • ADSL2+ Standards: ITU-T G.992.5
Data Rates ADSL downstream 24Mbps
Data Rates ADSL upstream 1Mbps
Wireless LAN
Transmit Power 20dB
Data Transfer Rate(s) Data Transfer Rates Up to 300Mbps
Encryption 64/128-bit WEP WPA-PSK WPA2-PSK
Frequency Band 2.4 to 2.4835GHz
Antenna Type 2x5dBi Omni directional, fixed
Wireless LAN Standards IEEE 802.11 b g n
Security
VPN Pass Through/Multi-Sessions PPTP • L2TP • IPSec
Security NAT Firewall • SPI Firewall • MAC / IP / Packet / Application / URL Filtering • Denial of Service(DoS) • SYN Flooding • Ping of Death
Ethernet
Protocols Supported ATM Forum UNI3.1/4.0 • PPP over ATM (RFC 2364) • PPP over Ethernet (RFC2516) • IPoA (RFC1577/2225) • PVC - Up to 8 PVCs • Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt • Dynamic Host Configuration Protocol (DHCP) • Network Address Translation (NAT) • DNS Relay, DDNS • IGMP snooping V1/2 • IGMP Multicast • UPnP
Ethernet Standards IEEE 802.3, 802.3u
Interfaces/Ports
LAN Ports 4 port(s) x RJ-45 10/100Mbps Ethernet
Modem Port 1 x RJ-11
Compliance
Standards CE, FCC, RoHS
System
Management Web Based Configuration (HTTP), Remote management, Telnet management, Command Line Interface, SSL for TR-069, SNMP v1/2c, SNMP over EOC, Web Based Firmware Upgrade, CWMP (TR-069), Diagnostic Tools
System Requirements
Operating Systems Supported Microsoft Windows 98SE/NT/2000/XP/Vista/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
Electrical
DC Input Voltage 9.0V DC
AC Input Current 0.8Amps
Environmental
Environmental Humidity 10 to 90% Operating Temperature 0 to 40°C
Physical
Form Factor Wireless Router
Case Colour White
LED Status Indicators Power, Internet, ADSL, WLAN, LAN1 to 4, QSS
In The Box 300Mbps Wireless N ADSL2+ Modem Router TD-W8961N, Power Adaptor, External Splitter (Optional), 2 x RJ-11 Telephone Cables, 1 x RJ-45 Ethernet Cable, Resource CD, Quick Installation Guide
Dimensions 19.5cm (W) x 13.0cm (D) x 3.6cm (H)
